Grundfos 3" Submersible Well Pump 10SQ07 200 3/4HP 230V

The Grundfos 10SQ07-200 is a 3/4 HP stainless steel submersible well pump rated for 10 GPM at 230V, designed for 3-inch well casings. Similar to the 10SQ07-240, this model is rated for a maximum head of 200 feet — ideal for shallower installations where the full 240-foot rating isn't required.

Specifications:

• Model: 10SQ07-200
• HP: 3/4
• Voltage: 230V
• Flow Rate: 10 GPM
• Wiring: 2-wire (no control box needed)
• Casing Size: Fits 3" well casing
• Construction: Stainless steel
• Max Head: 200 feet
• Soft Start Design Reduces Start-Up Amperage Draw

Perfect for instances where a 4-inch pump may not fit or there is danger of a 4-inch pump becoming rusted and stuck in 4-inch casing.

10SQ07-200 vs. 10SQ07-240 — What's the Difference? The only difference is max head rating: the -200 is rated to 200 feet and the -240 to 240 feet. If your well depth plus any pressure head required is under 200 feet, either will work. If you're near the limit, go with the -240 for headroom.
